Hollow Shaft Rotary Actuator
This robot hollow actuator is suitable for humanoid robots, exoskeletons, collaborative robots, automobiles, AGVs and other application scenarios
Robot integrated hollow actuator, integrated brake, dual encoding, harmonic reducer and drive,
Harmonic Actuator PRO Series
| Applications: | Humanoid robot, Quadruped robot, Exoskeleton robot, Rehabilitation robot, Wheeled robot, bipedal Robot, Robotic arm, others |
| Reducer ratio: | 51 | 81 | 101 | 121 | 161 |
| Nominal Voltage (V): | 24~48 |
| Nominal Current (A): | 1 | 2 | 3.6 | 5 | 6.1 | 9 | 14.1 | 15.8 |
| Nominal Power (W): | 36 | 90 | 150 | 300 | 500 | 750 | 1000 | 1500 |
| Nominal Speed (Rpm): | 7 | 12 | 17 | 18 | 22 | 23 | 24 | 25 | 27 | 29 | 30 | 34 | 35 | 37 | 38 | 40 | 43 | 44 | 45 | 46 | 54 | 61 | 68 | 75 | 80 | 90 |
| Nominal Torque (Nm): | 2.3 | 3.3 | 5.5 | 8.9 | 8.6 | 13.5 | 32 | 33 | 49 | 42 | 58 | 61 | 68.5 | 107 | 120 | 185 | 267 | 255 | 586 |
| Peak Current (A): | 2 | 3 | 5 | 6.7 | 8.4 | 10.4 | 16.9 | 30.2 |
| Peak Torque (Nm): | 3.3 | 4.8 | 8.3 | 11 | 23 | 29 | 34 | 42 | 53 | 66 | 63 | 91 | 102 | 108 | 121 | 169 | 194 | 207 | 217 | 267 | 376 | 411 | 436 | 459 | 503 | 802 | 841 |
| Backlash (arcsec): | 40 | 30 | 20 | 10 |
| Communication protocol: | CAN |
| Double Encoder: | Yes |
